The Bourg Document Finisher (BDF-e) is a high-end, compact and fully automated booklet maker. All parameters are controlled by a user-friendly color touchscreen interface in which stitching, folding, and trimming operations are completed in a single enclosed unit. This guarantees set integrity and a maximum speed of 4,200 booklets/hour.
The BDF-e is connectable with a BSF and seamlessly integrates the benefits of Off-Line and In-Line finishing, ideal for customers hesitating between Off-Line and In-Line finishing (see the description of the BSF).
Since the BDF-e can be directly connected to multiple print engines such as Kodak, Océ/Canon and Xerox,, it is the perfect choice for in-plants or commercial print shops that need to produce booklets in production runs from one to thousands.
Final dimensions of booklets produced by the BDF-e range from 76 x 120 mm (2.99 X 4.72 in) up to 260 mm x 356 mm (10.23 x 14.01 in) to a maximum speed of 4200 sets/hour.
The BDF-e is able to stitch fold trim up to 22 sheets, stitches up to 55 sheets, and folds up to 22 sheets (88 pages) booklets without scuffing or marking.
The BDF-e is compatible with several C.P. Bourg machines.
With the Bourg Sheet Feeder (BSF), for example, the BDF-e can be connected directly in In-Line and Near-Line mode to multiple print engines such as Xeror and Océ/Canon and Kodak and can quickly produce booklets.
Connected to the Bourg Bleed Crease Module (BCM-e), the BCM-e will perform the highest quality knife creasing, top and bottom bleeding. Adding the Square Edge Module (SQE) to the configuration will transform traditional stitch-fold-trim booklets into square edged booklets. Booklets produced are flat and easy to stack.
STANDARD FEATURES | ||
Features | Advantages | Benefits |
Folds up to 88 page booklets Stitches up to 55 sheets |
|
|
---|---|---|
Graphical User Interface (GUI) |
|
|
In-operation adjustments |
|
|
Stitch fold trim |
|
|
2 to 4 stitch heads |
|
|
DELUXE head features |
|
|
Purge FEATURE |
|
|
Face trimmer |
|
|
OPTIONS | ||
FEATURES | ADVANTAGES | BENEFITS |
Loop Stitch |
|
|
---|
Media (IN OFF-LINE MODE) | |
Maximum Speed | 4,200 booklets/hour (5 A4 sheets, 90 gsm) |
Paper weight | 60 to 300 gsm |
Face trimming | 0 to 20 mm (0 to 0.78 in) |
SAddle stitching | |
---|---|
Minimum paper size * | 120 x 203 mm (4.72 x 8 in) |
Maximum paper size | 356 x 520 mm (14.01 x 20.47 in) |
Booklet thickness (with fold and cut) | 2 to 22 sheets of 80 gsm or equivalent (cover included) |
TOP/side stitching | |
Minimum paper size * | 120 x 76 mm (4.72 x 3 in) |
Maximum paper size | 356 x 297 mm (14.01 x 11.69 in) |
Booklet thickness (without fold nor cut) | 2 to 55 sheets of 80 gsm or equivalent (cover included) |
Folding/trimming | |
Minimum paper size * | 120 x 76 mm (4.72 x 3 in) |
Maximum paper size | 356 x 260 mm (14.01 x 10.23 in) |
Booklet thickness (fold and cut) | 2 to 22 sheets (8 to 88 pages) of 80 gsm or equivalent (cover included) |
* Software limitation to 127 mm (5 in) (instead of 120 mm - 4.72 in) in some particular cases |
Physical | |
Dimensions (L x W x H) | 158 x 61,3 x 194,3 cm (62.20 x 24.13 x 76.49 in) |
Weight | 450 kg (990 lbs) |
Delivery conveyor | 90 cm (35.43 in) |
Electrical / Acoustic | |
Power supply | 120V ±10%, 60Hz, 10A 230V ±10%, 50Hz, 7A |
Operational mode | |
---|---|
Power consumption | 750 W |
Radiant heat | 2,600 BTU/hour |
Sound level | 70 dB |
Standby mode | |
Power consumption | 150 W |
Radiant heat | 600 BTU/hour |
BDF-e Document Finisher family (Stitch-Fold-Trim) with 2 Deluxe Stitch Heads
BDF-e Document Finisher family (Stitch-Fold-Trim) with 4 Deluxe Stitch Heads
BDF-e Document Finisher family (Stitch-Fold-Trim) with 2 Hohner Stitch Heads
BDF-e Document Finisher family (Stitch-Fold-Trim) with 4 Hohner Stitch Heads
BDF Bourg Kit to upgrade BDF 2 regular Hohner heads to loop stitch configuration (this kit includes a deflector, Hohner stitch heads are not included, only accessories)
BDF-e Document Finisher family 4 Hohner transformation kit to make loop stitches (this kit includes a deflector, Hohner stitch heads are not included, only accessories)
Docking plate to connect BDFE(x) to BSF or centered printer
Registration plate and jacks for BDF-e when connected to registered printer or asymmetric cut on BCM-e
Xerox Spare Parts Kit for BDF-e / BDFN-x
BDF-e / BDFN-x adaptation kit to be connected with DocuColor 8000 (speed adaptation)
BDF-e / BDFN-x adaptation kit to be connected with iGen family (speed adaptation)
BDF-e / BDFN-x adaptation kit to be connected with DocuColor 6060 family (speed adaption)
BDFE-x / BDFN-x input height conversion kit (to get 1020mm high input) - docking included, registration plate 9591921-X not included
